Description
The TurboMax 2 is a compact yet powerful machine designed for residential and light commercial air system cleaning. With its dual-speed motor and advanced filtration system, it provides efficient and thorough duct cleaning, while its portable design makes it easy to handle and transport.
Key Features:
- Compact and Portable: Easy for one person to operate, even up and down stairs.
- Powerful Performance: The 2 HP single speed/single phase motor delivers 2000 CFM of air flow at 5” static pressure, ensuring efficient cleaning.
- Advanced Filtration: The 3-stage HEPA filtration system includes:
- 1st Stage: 18″ x 24″ x 2″ disposable pleated bag filter
- 2nd Stage: 18 1/4″ x 24 1/4″ x 1″ permanent electrostatic air filter
- 3rd Stage: 18″ x 24″ x 6″ certified HEPA filter
- Easy to Maneuver: Features 12″ rear non-marking dolly wheels and 4″ front swivel non-marking casters.
- Durable Construction: Made from steel-reinforced aluminum with a professional-looking, non-marking powder-coated finish.
- Reliable Operation: Field-tested by Air-Care and backed by a 3-year limited warranty.
Specifications:
- Size: 19.5″ W x 29″ D x 55.5″ H
- Weight: 125 lbs
- Power Required: 120 V, 60 Hz, 13 to 17 amps
- Power Cord: 25-foot extension cord
- Filtration: 4-stage with Pellon Pre-Filter Pad + 1″ Frame
- Pre-Filter: Pellon Moisture Barrier
- 1st Stage: 18″ x 24″ x 1″ disposable polyester filter pad
- 2nd Stage: 16.75″ x 22″ x 1″ electrostatic air filter
- 3rd Stage: 18″ x 24″ x 4.71″ certified HEPA filter
- Attachment: 12″ diameter inlet
- Operating Environment: 25 to 125°F (-4 to 50°C)
- Construction: Rotation molded poly
- Operating Controls: Single pluggable panel with all gauges, indicators, switches, and meters
- Air Flow: 2500 CFM free air / 2000 CFM filtered
- Static Pressure: 5.0″ W.G.
- Motor: 2 HP single phase/single speed, 120 Volt
- Blower: Backward inclined
- Wheels: Two 12″ fixed rear and two 4″ front swivel non-marking wheels
Why Choose TurboMax 2?
The TurboMax 2 is designed to make residential air system cleaning easier and more efficient. Its compact size, powerful performance, and advanced filtration system ensure thorough cleaning every time. Whether you’re cleaning a small home or a light commercial space, the TurboMax 2 is the perfect tool for the job.
For more details and to place an order, contact us at 800-322-9919 or email sales@air-care.com.
TurboMax Negative Air Machine Comparisons
| Feature | TurboMax 3 | TurboMax 2 – 1.5 | TurboMax 1 |
|---|---|---|---|
| Application | Commercial and Residential | Light Commercial and Residential | Residential |
| Free Air CFM | 5000 | 3000 | 2500 |
| Filtered CFM | 3500 | 2700 | 2000 |
| Motor Type and HP | 3 HP, Single Phase, Inverter Rated, 3 Phase Motor, 3600 RPM | 2 HP, 3 Phase Motor and One Single Phase Inverter with Soft Start and Dual Speeds | 1 HP, Single Phase/Single Speed, 120 Volt |
| Power Source and Line Conditioning | Proprietary power doubler and line conditioning software with ground safety interlock coupled to a 3 HP variable speed Inverter with overload and undercurrent detection | Single phase input, 1.5 HP variable speed inverter with error sensing logic and protection circuits | Single phase, single speed direct wiring to motor |
| Blower Wheel | Direct drive backward inclined 315mm (12.3″) diameter blower wheel | Direct drive backward inclined 280mm (11″) diameter blower wheel | Direct drive backward inclined 280mm (11″) diameter blower wheel |
| Size | 19.5” W x 29” D x 55.5” H | 22.5″ W x 31.5″ D x 55.5″ H | 19.5″ W x 29″ D x 55.5″ H |
| Weight | 146 lbs | 125 lbs | 125 lbs |
| Warranty | 3 Year | 3 Year | 3 Year |
| Soft Start | Yes | Yes | No |
| Speeds | 4 | 2 | 1 |
